Features ①Cartridge ②Balanced ③Independent of direction of rotation ④Stationary multiple springs ⑤Springs and pin located on the atmospheric side Advantages ①Extremely short length design ②the total length including the seal cover is less than 50 mm ③Easy installing on the pumps without modifying the stuffing box ④Excellent followability due to no influence from run-out, squareness or vibration of the shaft ⑤Mounted outside the stuffing box for providing excellent air cooling performance ⑥Un-wetted springs and knock pins for protecting from lockout by liquid
Operating range: Pressure: p = … 20 bar (290 PSI) Temperature:t = -20 °C …160 °C (-4 °F ... 320 °F) (oil),0 °C ... 60 °C (32 °F ... 140 °F) (water) Sliding velocity:vg = max. 20 m/s (66 ft/s) Viscosity: 0.5 Pa·s Solids content: 0.3 %
Combined Materials: Seal face: High density carbon graphite Seat: Silicon carbide (Q1) Metal parts: CrNiMo steel (G) Secondary seals: FKM (V)
Recommended applications: Petrochemical industry Chemical industry Pharmaceutical industry Pulp and paper industry Water and waste water technology Food and beverage industry Universally applicable Centrifugal pumps Eccentric screw pumps process pumps
