The mechanical seal can be reassembled after cleaning, inspection and technical dimension check. In this process, the following points should be paid attention to:
1.All sealing rings should be coated with soapy water and other lubricants, so as to avoid damaging the rubber rings during the assembly process. Grease should be applied between the sealing surfaces of the rotary face and stationary seat to prevent them from wearing before the pump starts.
2.When assembling the floating ring, be careful not to knock down the floating ring spring, so as not to affect the floating performance of the floating ring. After finishing assembling, you can gently press the floating ring to determine whether there is good floating performance.
3.Handle with care to prevent damage to the mechanical seal. The seal and cavity should be cleaned during installation.
4.When tightening the gland, the tightening bolts should be evenly stressed otherwise uneven force will damage the mechanical seal. For quick-fitting mechanical seals, do not forget to fix the position of the positioning piece radially away from the shaft after the overall assembly is completed.
The mechanical seal can be assembled without leakage and other problems as per as the above steps. However, there is no uniform solution to different situations during maintenance, because the sealed medium of the mechanical seal is different. Meanwhile,the pressure in the chamber is different, and the design of the mechanical seal is It will be different, and the maintenance process will also be different. This requires us to be flexible in the maintenance work, and only in this way can we ensure the quality of the maintenance.
（ If you want to view other products，pls visit this website & component seals ）
