There are two types of mechanical seal faces grinding technologies: manual grinding and mechanical grinding.Manual grinding is mainly used for small -scale one-piece production and repair work.Mechanical grinding is used in large quantities. The following introduces mechanical grinding.
Mechanical grinding is to grind the workpiece on the rotating grinding gear. The abrasive gear is generally a circular grinding plate. Mechanical grinding plates are usually cast iron, and the polishing discs are steel plates or copper plates.Velvet and silk plates are often used for polishing sealing rings of such materials as hard alloy, copper alloy, and stainless steel. The surfaces of the metal grinding plates must be flat without flaws. The plates need to be trimmed till its flatness below 0.05/1000mm.The radius of the disc should be designed at least twice the diameter of the processed workpieces. Its diameter range is generally 305 ~ 1620mm (16 ~ 64in), and the thickness is roughly 1/10 ~ 1/6 of the diameter. There is a groove on the plate surface. The purpose of slotting is to reduce the stress deformation of the plate surface and to make it easy to dissipate heat.Also,during the grinding process,it is more convenient to remove and accommodate the dross.
The grinding machine is a grinding equipment used in the mechanical seal manufacturing industry. It is composed of bed body, base, reducer, grinding plate, control ring (also known as a block or correction ring), and limited supporting rack. During grinding, the workpiece is arranged evenly in the control ring with a plastic isolation ring,and grinding pressure is applied by physical
pressure.When grinding plate rotates,the control ring rotates in the limited supporting rack.Thus,the workpiece not only rotates by itself but also rotates with the control ring on the grinding plate.Under the acting of the abrasive,the mechanical seal faces are constantly being ground.This is the basic working principle of grinding machine.
（ If you want to view other products，pls visit this website & component seals ）
